Developed in 1989, Centennial Plaza comprises three modern high rise office buildings with a total office NLA of 52,745 sqm with ground floor retail tenancies totaling approximately 896 sqm (Total NLA of 53,641 sqm) and basement car parking for 433 cars. The buildings range in height from 10 storeys (260 Elizabeth Street) to 16 storeys (300 Elizabeth Street).

The buildings are situated on an island site of 13,191 sqm which provides an abundant ground floor amenity including extensive landscaped grounds with mature trees, gardens and paved forecourt areas.

Location

Centennial Plaza occupies a high-profile position on Elizabeth Street, directly opposite Central Railway station, the largest rail and bus terminal in Sydney.

Elizabeth Street is one of Sydney’s main thoroughfares running virtually the entire distance of the Central Business District, from Central station North towards Sydney Harbour.

Deliveries

All deliveries are to be made via the Loading Docks for each Tower. The loading dock is open from 7am to 6.00pm Monday to Friday (excluding Public Holidays).

Access to the Loading Dock is via Albion St for Tower A and via Mary St for Towers B & C. Height access limits for each is 3.2m.

All after hours contractor or deliveries can be organised by contacting Centennial Plaza Building Management or Security on (02) 9281 8600

Parking

The building car park is operated by CBRE Building Management who may be contacted on (02 9281 8600).

There are 433 car parking bays located on the basement & sub-basement across the 3 Towers. Access to the car parking levels is by way of the dedicated Lifts.

The car park operates between 7am to 6pm, Monday to Friday, however those with permanent parking spaces have access 24/7 via an access card.

DIVVY Parking – Tower C, 300 Elizabeth Street, also has the DIVVY Parking Facility in operation. This facility offers some casual daily parking to the general public at discounted rates. All bookings and payments for this facility are done via the DIVVY App. Simply download the App, book and pay online.

Technical Specifications

NUMBER OF FLOORS

  • Total of Ten (10) office floor levels
  • One carpark level
  • Separate loading dock
  • Ground floor

TYPICAL OFFICE FLOOR SPECIFICATION*

  • Occupancy loading – 1 person per 10sqm
  • Lighting Load – 20 Watts per sqm
  • Equipment Load – 15 Watts per sqm
  • Outside air rate – 5 l/s per sqm
  • Supply air rate – 5 l/s per sqm
  • Performance glazing with glare control

VERTICAL TRANSPORTATION

  • Four (4) lifts servicing B1 to level 10
  • Stretcher facilities
  • Disabled facilities

FIRE SERVICES

  • Smoke Detection Systems with self analysis capabilities
  • Flexible arrangements for fire protection on floor fitouts
  • Emergency Warning and Intercommunications Systems
  • Sprinkler and Hydrants Systems installed

ELECTRICAL SERVICES

  • 100A per floor providing 50 VA per sqm

STANDBY POWER

  • Emergency Diesel Generator supporting essential services only
  • Bulk fuel storage tank

AIR CONDITIONING

  • Central Plant
  • Floor by floor air handling units
  • Typical office floor – Centre and perimeter zone with average 14 x VAV

AUXILIARY SERVICES

  • Fully digital Building Management Control System (BMCS),
    monitoring all building functions, including energy consumption and air conditioning services
  • Security and access control to perimeter doors and lifts
  • Security personnel provide 24 hour, 7 day monitoring of facility
  • Secure Parking facilities

NUMBER OF FLOORS

  • Total of Thirteen (13) office floor levels
  • Two (2) carpark levels
  • Ground floor entry
  • Adjacent Retail arcade

TYPICAL OFFICE FLOOR SPECIFICATION*

  • Occupancy loading – 1 person per 10sqm
  • Lighting Load – 20 Watts per sqm
  • Equipment Load – 15 Watts per sqm
  • Outside air rate – 5 l/s per sqm
  • Supply air rate – 5 l/s per sqm
  • Performance glazing with glare control

VERTICAL TRANSPORTATION

  • Five (5) passenger lifts servicing B2 to level 13, and One (1) servicing carpark levels to retail arcade
  • Stretcher facilities

FIRE SERVICES

  • Smoke Detection Systems with self analysis capabilities
  • Flexible arrangements for fire protection on floor fitouts
  • Emergency Warning and Intercommunications System
  • Sprinkler and Hydrants installed

ELECTRICAL SERVICES

  • 100A per floor providing 53 VA per sqm
  • Dedicated tenant data & voice riser

STANDBY POWER

  • Emergency Diesel Generator supporting base building essential fire

SERVICES

  • Bulk fuel storage tank

AIR CONDITIONING

  • Central Plant
  • Floor by floor air handling units
  • Typical office floor – Centre and perimeter zone with average 14 x VAV
  • Tenant Condenser Water loop available for use by tenant

AUXILIARY SERVICES

  • Fully digital Building Management Control System (BMCS), monitoring all building functions, including energy consumption and air conditioning services
  • Security and access control to perimeter doors and lifts
  • Security personnel provide 24 hour, 7 day monitoring of facility
  • CCTV system covering building points of entry and retail promenade

NUMBER OF FLOORS

  • Total of sixteen (16) office floor levels
  • Two (2) carpark levels
  • Ground floor entry x 2
  • Adjacent retail arcade

TYPICAL OFFICE FLOOR SPECIFICATION

  • Occupancy loading – 1 person per 10 sqm (based on OA rate of 7.5 l/s per person. Max. 130 occupants per floor)
  • Lighting Load – 10 Watts per sqm
  • Equipment Load – 20 Watts per sqm
  • Outside air rate – 7.5 l/s per occupant
  • Supply air rate – 7380 l/s total or 5.671 l/s per sqm
  • Performance glazing with glare control. SHGC 0.5 (estimate)

VERTICAL TRANSPORTATION

  • Seven (7) passenger lifts servicing B2 to level 16, and one (1) servicing carpark levels to retail arcade
  • Stretcher facilities

FIRE SERVICES

  • Smoke Detection Systems with self analysis capabilities
  • Flexible arrangements for fire protection on floor fitouts
  • Emergency Warning and Intercommunications System
  • Sprinkler and Hydrants Systems installed

ELECTRICAL SERVICES

  • Typical office floor (levels 1 to 16) up to 70 VA per sqm
  • Dedicated tenant data and voice riser

STANDBY POWER

  • Emergency Diesel Generator supporting base building essential fire services
  • Bulk fuel storage tank
  • Emergency Diesel Generator supporting nominated tenants loads up to 40 VA per sqm

AIR CONDITIONING

  • Central Plant
  • Floor by Floor air handling units
  • Typical office floor – Centre and perimeter zone with average 15 x VAV
  • Tenant Condenser Water loop available for use by tenant

AUXILIARY SERVICES

  • Fully digital Building Management Control System (BMCS) monitoring
    all building functions, including energy consumption and air conditioning services
  • Security and access control to perimeter doors and lifts
  • Security personnel provide 24hr, 7 day monitoring of facility
  • CCTV system covering building points of entry and retail promenade

Note: The above figures are indicative only and can change. For each tenancy requirements the building engineering consultants must be contacted to assess their specific requirements.
